Watter’s Pointe

3370 Greenbank Rd Barrhaven

Units

260

Unit Styles

Townhomes

Our townhomes offer the living experience and joy of a full sized home in a manageable and compact style. The design of our townhomes ensure plenty of natural light, spacious and well designed open concept lay-outs and stylish exteriors. Find a floorplan that matches your lifestyle and take the next step to owning a Claridge townhome today.


3370

Greenbank Rd
Barrhaven

Features

Back2Back Townhomes


  • Foundation And Concrete Floors
  • Steel reinforced 8” concrete foundation walls
  • Cement parging to exterior of exposed concrete walls
  • Drainage layer system to exterior foundation walls
  • 4” perimeter drainage tile system
  • 3” concrete basement floor with troweled finish
  • Reinforced concrete garage floor with broom finish

  • 9’ framed ceiling heights at the second floor
  • 8’ framed ceiling heights at the ground and third floor
  • Pre-Engineered floor joist and roof truss system
  • Steel beams and teleposts as per plan
  • Sub-floor: 3/4” tongue-and-groove sheathing glued, nailed, sanded and screwed down
  • Underlay: 5/8” added to sub floor under ceramic tile
  • Exterior wall (except garage) 2”×6” studs at 16” centers
  • 2”×4” interior walls and 2”×6”/8” mechanical walls. Studs as per plans
  • Basement exterior frost walls framed to floor with 2”×4” studs at 24” centres as per plan
  • Party wall (between dwellings, all levels except basement and attic) two separate 2”×4” stud walls at 16” centres with sound deadening insulation and 5/8” fireresistant gypsum board each side. Party walls at basement level to be 8” steel reinforced poured concrete; height as per plans

  • Front entry door system, contemporary design, full lite frosted glass insert complete with one full clear side lite panel, insulated door with weather-stripping
  • E-Star Zone 2 casement and fixed windows as per plan
  • Oversized thermal sliders in basement as per plan
  • Garage man-door, metal insulated with weather-stripping
  • Sliding patio door at balcony as per plan
  • Steel, sectional, insulated, overhead garage door with insulated glass inserts
  • Garage door opener c/w keyless entry, one (1) remote and switch at garage man-door
  • Second floor balcony with composite decking
  • Brick, vinyl siding/cement board and contemporary stone pre-cast sills (as per plan)
  • Prefinished soffits and fascia as per plan
  • Pre-selected exterior designer elevation colour packages
  • Architectural roof shingles with manufacturer’s lifetime warranty
  • Exterior house wrap, except garage
  • Mail box and civic address numbers

  • Rigid insulation below footings and basement slab (R8.6)
  • R22 insulation in all exterior walls, except garage
  • R12 insulation in basement frost walls, with additional R12 continuous insulation behind frost walls
  • R60 insulation in attic where height permits
  • R32 in garage ceiling with floors above
  • Expandable foam injection around windows and exterior doors
  • 6 mm polyethylene vapour barrier
  • Fully drywalled garage with ½” gypsum and one-coat finish
  • Smooth finish on ground and second floor ceilings throughout
  • Interior wood trim and doors to be white semi-gloss finish
  • Wall paint is to be white latex flat finish. Latex semi-gloss for all bathroom andkitchen wall
    • img

    Location + Surroundings

    Our townhomes offer the living experience and joy of a full sized home in a manageable and compact style. The design of our townhomes ensure plenty of natural light, spacious and well designed open concept lay-outs and stylish exteriors. Find a floorplan that matches your lifestyle and take the next step to owning a Claridge townhome today.
